Exposure 2510 Integrated Amplifier
Range £1,850
Description
The Exposure 2510 Integrated Amplifier offers an impressive 75W of amplification for class-leading sound accuracy. Fully featured with all the latest cutting-edge technology, the 2510 will guarantee a musical performance you will want to repeat.
Standard Free UK Delivery Over £75 (3-5 working days)
Key Features
- 75W RMS per channel into 8 Ohms
- Five line inputs
- MM Phono Stage fitted as standard
- Separate Pre-Amp output
- High quality capacitors used in the signal path
- Uniquely tuned short signal and Power Supply path PCB
- Cascode circuitry utilised for improved Power Supply immunity
- Fast bipolar transistor output stage for dynamic and vivid performance
- All aluminium casework and extruded front panel to control resonance and stray electro-magnetic fields
- Remote control
Key Specification
- Power Output (1KHz): 75 Watts per channel into 8 Ohms
- Total Harmonic Distortion: <0.015% at 1Khz, rated power
- Frequency Response: 20Hz to 20KHz +/-0.5dB
- Signal To Noise Ratio ref 1KHz & 75W output : >100dB, A weighted
- Channel Separation: >60dB @ 1KHz LINE input open (shorted >80dB), >40dB @ 20KHz LINE input open (shorted >60dB)
- Pre Amplifier Output: +12dB ref LINE input
- Frequency Response: 20Hz to 20KHz +/-0.5dB /
- Signal To Noise Ratio ref 1KHz & 1V output : >100dB, A weighted
- Channel Separation @ 20KHz >60dB input shorted, >40dB input open AUX2 input
- AV Input Fixed Level: 850mV @ 1KHz, 10K Ohms, S/N >100dB
- AUX 1 Phono Input MM: 2.5mV @ 1KHz, 47K Ohms, S/N >72dB
- LINE Inputs (Except AV): 350mV @ 1KHz, >14K Ohms, S/N >100dB
- Mains Supply: 110/120V or 220/240V @ 50/60Hz (factory set)
- Fuse: T5AL for 110/120V unitsT2.5AL for 220/240V units
- Power Consumption: <200W
- Dimensions (WxHxD): 440 x 90 x 300 mm (inc knob)
- Net Weight: 6 kg
- Gross Weight: 8 kg
